Blog TOSUNlux | Informations sur les technologies électriques et d'éclairage

Blog

Comprendre les transformateurs : quelle est la différence entre TC et PT ?

07th Mar 2026

CTs and PTs are both instrument transformers, but they do not serve the same measurement purpose. A current transformer is used when current needs to be reduced to a measurable level for meters or protection devices. A potential transformer is used when voltage needs to be stepped down for safe measurement and control. For buyers, the practical question is not just the definition, but which one is required for the metering or protection task in the system. CT vs PT: Key Differences Overview Feature Current Transformer (CT) Potential Transformer (PT) Measurement Focus Current measurement Voltage measurement Input Range High current (e.g., 100A to 5,000A) High voltage (e.g., 11kV to 400kV) Output Range Low, safe current (e.g., 5A or 1A) Standardized low voltage (e.g., 110V) Common Uses Industrial and substation current monitoring Power transmission voltage monitoring Accuracy High for current at varying loads High for voltage at fixed ratios Key Differences Between CT and PT Primary Function CTs measure current by stepping down high current levels, while PTs measure voltage by reducing high voltage to a safer level. Design and Construction CTs are built to handle high currents, often featuring a toroidal design. PTs, in contrast, are designed for precise voltage scaling, with insulation suited for high-voltage applications. Accuracy and Load Handling CTs are optimized for current accuracy under varying load conditions. PTs prioritize voltage precision to ensure accurate metering and relay operation. Applications CTs are ideal for industrial systems requiring current monitoring, while PTs are essential for transmission and distribution systems requiring voltage control. When […]
En savoir plus
Comment choisir des disjoncteurs CC adaptés ?

06th Mar 2026

Selecting a suitable DC MCB starts with the circuit itself, not with the breaker catalog. In DC applications such as solar PV, battery systems, and control circuits, breaker selection should match the system voltage, operating current, fault level, and installation environment. A breaker that looks suitable by ampere rating alone may still be wrong for the actual DC circuit. This guide explains the practical selection process for buyers, panel builders, and installers. What Is a DC MCB? A DC MCB, or Direct Current Miniature Circuit Breaker, is a small device that helps protect electrical circuits. As a type of circuit breaker, it works by stopping the flow of electricity when the current gets too high, preventing damage to appliances and reducing the risk of electrical fires. Circuit breakers also help prevent electric shock, ensuring system safety and protection. Key Features of DC MCBs: Why Use a DC MCB? Protection Against Short Circuit Step-by-Step: How to Select a Suitable DC MCB Key Parameters to Check Before Ordering When selecting a DC miniature circuit breaker (MCB), it’s important to ensure safety and efficiency in your electrical systems. Here are some key factors to consider: By considering these factors, you can choose a DC MCB that effectively protects your electrical systems, ensuring both safety and reliability. Common Mistakes in DC Breaker Selection One common mistake is choosing a breaker only by current rating while ignoring the DC voltage requirement. Another mistake is treating AC and DC breakers as interchangeable products. Even if the ampere value looks similar, the […]
En savoir plus
Le guide ultime du micro-interrupteur

05th Mar 2026

Découvrez leur conception ingénieuse, leurs applications dans diverses industries et les avantages qui les rendent indispensables.
En savoir plus
Compteur d'énergie vs compteur de puissance : quelle est la différence ?

04th Mar 2026

Energy meters and power meters are related, but they are not used for the same purpose. An energy meter is mainly used to record how much electricity has been consumed over time, while a power meter shows how much power is being used or generated at a specific moment. For buyers, the real decision is based on application: billing, consumption tracking, equipment monitoring, or energy optimization. What Is an Energy Meter? What is an energy meter? An energy meter, also known as an electrical energy consumption meter or electric energy meter, is a device that measures the total amount of electrical energy consumed over a period of time. They are commonly used in residential, commercial, and industrial settings to track and record the cumulative energy usage in kilowatt-hours (kWh). The primary function of an energy meter is to integrate power consumption over time, providing an accurate measurement of the total electrical energy used. Energy meters come in various types, including electromechanical, electronic, and smart meters. Electromechanical meters use a rotating disc that spins faster as more power is consumed, with the rotations being counted to determine the total energy used. Electronic meters, on the other hand, utilize digital circuitry to measure and calculate energy consumption. Smart meters are advanced electronic meters that offer additional features such as remote reading, time-of-use tariffs, and two-way communication with the utility company. What Is a Power Meter? What is a power meter? A power meter is a device that measures the instantaneous electrical power being consumed or generated at […]
En savoir plus
Le capteur à micro-ondes est-il sûr ?

03rd Mar 2026

Microwave sensors are generally considered safe for normal commercial and residential use because they operate with low-power microwave signals for motion detection, not high-energy radiation for heating or processing. For buyers, the more practical question is not only whether the sensor is safe, but whether it is suitable for the installation environment. Microwave sensors are often chosen for larger areas, hidden installation positions, or applications where detection through thin materials is useful. This article explains how they work, what affects safety and performance, and when a microwave sensor is a better choice than a PIR sensor. What Is A Microwave Sensor? A microwave sensor is a type of motion sensor that uses microwaves to detect movement. Think of it like a bat using sonar, but instead of sound waves, it sends out microwave signals. These signals bounce off objects and return to the sensor. If something moves, the signal changes, and the sensor detects it. Microwave sensors can detect objects up to 45,000 mm away, even through thin walls and glass. They are highly reliable and have no moving parts, making them ideal for military and security applications. Unlike other sensors, microwave sensors can work in rooms with low temperatures and are more sensitive than passive infrared (PIR) sensors. This makes them perfect for large areas like warehouses and outdoor spaces. Types of Microwave Sensors There are several types of microwave sensors, each designed for specific applications: When to Choose a Microwave Sensor Instead of a PIR Sensor A microwave sensor is often preferred when […]
En savoir plus
Taille optimale des fusibles des panneaux solaires : assurez la sécurité de votre système

02nd Mar 2026

Choosing the right solar fuse size is not just about matching a number on the panel label. In a real PV system, fuse selection depends on where the device is installed, how many strings are connected in parallel, and what current the circuit may actually carry under fault conditions. For buyers and installers, the key question is simple: which part of the solar system needs fuse protection, and what fuse rating is suitable for that section? This guide explains the selection logic in a more practical way. Key Takeaways Understanding Solar Panel Fuses Solar panel fuses are essential for safeguarding your solar panel system. They protect against: Why Proper Fusing is Important How to Determine the Right Fuse Size Benefits of Proper Fusing Where Solar Fuses Are Used in a PV System Solar fuses are not selected in isolation. In a PV system, they are usually considered together with DC breakers, isolators, and surge protection devices. At the string level, PV fuses are commonly used to protect individual strings against reverse current from parallel strings. In combiner boxes, fuses may work together with DC breakers and SPDs to improve fault protection and maintenance safety. On the inverter side, the protection design may also include DC isolators or AC breakers depending on the system layout. That means buyers should first confirm the installation position before choosing the fuse rating. Calculating the Correct Fuse Size for Your Solar Panels Calculating the correct fuse size for your solar panels is essential to ensure safety and efficiency. Here’s how […]
En savoir plus
L'impact du couple de serrage des bornes sur la surchauffe des disjoncteurs

28 février 2026

In the field of electrical engineering, safety is determined by a secure connection and the circuit breaker. During electrical installations, terminal torque is often overlooked. This is defined as the “perfect tightness” of rotational force applied to the terminal screws. When the necessary rotational force is not properly applied, your circuit breaker is compromised. According to Joule’s Law, resistance generates heat and increases with the square of the current and the resistance of the connection. This is shown by the formula P = I2R. To prevent rapid overheating, the correct terminal torque should be applied to a circuit breaker. Real-World Scenarios and Operational Risks In industrial and commercial electrical systems, engineers may impose safety measures. However, these may contradict certain site conditions. There may also be instances where circuit breaker failures are caused by human factors. Understanding how proper terminal torque affects the circuit breaker is essential for electrical fire prevention. Below are some real-world scenarios demonstrating the operational risks caused by incorrect terminal torque conditions: Loose Wiring & Thermal Cycling In busy factories, the vibrations coming from heavy machinery may cause tightened terminals to loosen. In electricity, when the lug doesn’t make full contact with the terminal, this creates electrical resistance. As resistance increases, so does the temperature. This results in a dangerous loop called “thermal cycling.” One of the solutions to thermal cycling is to ensure that the initial “preload” on a bolt or screw is correct. Use a calibrated torque wrench and follow the manufacturer’s specific N · m (Newton-meter) or in.lb […]
En savoir plus
Problèmes de déclenchement du RCCB et comment les résoudre

27 février 2026

If your RCCB keeps tripping, do this in order: Safety: RCCBs protect against earth leakage and shock risk. Don’t keep “forcing it ON” repeatedly. Residual current circuit breakers tripping problems can result from issues like moisture, faulty wiring, or damaged appliances. Fixing these problems involves steps such as resetting the breaker, inspecting wiring, and testing devices. If you’ve ever wondered why your RCCB trips unexpectedly, this guide is here to help. TSL3-63 Residual Current Circuit Breaker TSL3-63 Residual Current Circuit Breaker The TSL3-63 RCCB provides enhanced protection against overload and short-circuit faults in AC electrical circuits, ensuring safety in various industrial and residential applications. View Product Troubleshooting Flow Step A — When does it trip? Step B — Quick isolation test (safe, homeowner-level) If you find the device that triggers the trip, repair or replace it. Step C — When to stop DIY and call an electrician Electricians can use leakage current meters and insulation testers to pinpoint hidden faults. Why Residual Current Circuit Breakers Trip Moisture often causes ground faults by allowing current to leak through wet or damaged wiring. This issue is common in areas like bathrooms, kitchens, or outdoor circuits. Moisture can cause earth leakage, leading to RCCB tripping to prevent electrical hazards. Start by drying wet areas and sealing conduits to prevent water intrusion. If damage is severe, replacing the cables may be necessary. Frayed wires or loose terminals can cause leakage currents, leading to RCCB tripping. Current flowing through damaged wires can cause imbalances, prompting the RCCB to cut off the power […]
En savoir plus
Fabrication de disjoncteurs : L’importance des contacts en argent / Fabrication de disjoncteurs

27 février 2026

Electricity is a powerful force that requires a dependable, rigorously tested “emergency shut-off valve.” In circuit breaker manufacturing, manufacturers focus on building a device that cuts off power if it senses too much electricity. The circuit breaker acts as a defense mechanism for electrical systems. If the power is not interrupted at the right time, a simple overload can result in a fire. Standard metals often fail when electrical switching happens due to extreme thermal and mechanical stress. Engineers solve this problem by using silver alloy contacts. Silver is conductive, and the alloy strengthens it so it can survive arcing. This article explains the importance of silver alloys in circuit breaker manufacturing. What Are Electrical Contacts? Electrical contacts are physical points in an electrical system where a circuit meets. They are composed of two conductive pieces that touch. This action allows power to flow and separates to stop it. The role of the circuit breaker is to keep the contacts pressed together. It also triggers a mechanism (separator) during a power surge, so the contacts will pull apart. A Dual Responsibility Contacts have a dual responsibility when it comes to electrical safety. When closed, they must remain in contact and carry a stable current without overheating. On the other hand, when they are open, they must withstand the force of an electrical arc. Inherent Industrial Challenges In circuit breaker manufacturing, the choice of material is one of the most critical decisions. Heat generation and mechanical wear are two of the problems that a contact may […]
En savoir plus
Choisir le disjoncteur adapté à votre centre de données pour une alimentation électrique continue

26 février 2026

In today’s modern-day digital economy, a data center is the most valuable system. A poorly designed breaker system can shut down an entire data center due to a minor fault. While most establishments use generators and UPS systems, Tier III and Tier IV facilities demand uptime standards of 99.982% and 99.995% availability. This is why circuit breakers play a vital role in the data center breaker system. This article discusses the different circuit breakers that you can choose from depending on your industry’s needs. You can select from Miniature Circuit Breakers (MCBs), Molded Case Circuit Breakers (MCCBs), and Air Circuit Breakers (ACBs). You will also learn why selection coordination, power availability, uptimes, and TCC analysis are vital in data center operations. Real-World Applications of How Establishments Use Data Centers Data centers are the heart of modern global infrastructure. Various industries rely on these facilities to manage and store vast amounts of information. If these data centers are compromised, business continuity and secure operations may also be at risk. To help you understand the importance of a data center breaker, here are the top three establishments that utilize data centers: Banks and Financial Institutions Every time a customer uses an ATM or a mobile banking app, a data center processes the request in milliseconds. For these establishments, the highest priority is power availability. A few seconds of a power dip could result in lost transactions, corrupted financial records, and security breaches. Hospitals and Healthcare Providers Hospitals use data centers to store electronic health records (EHR), operate […]
En savoir plus
