Solar PV Cable Single Core

Basic Information
  1. Model 1.5mm, 2.5mm, 4mm, 6mm, 10mm, 16mm, 25mm, 35mm

Product Description

Specification

Construction (mm2)    Conductor Construction           (n x m) Conductor Outer Diameter (mm) Cable Outer Diameter (mm) Resistance Max.
Ω/ km
Current Carrying
Capacity AT 60°C
(A)
1×1.5 30×0.25 1.58 4.90  13.70  30
1×2.5 48×0.25 2.02 5.45  8.21  41
1×4 56×0.3 2.35 6.10  5.09  55
1×6 84×0.3 3.20  7.20  3.39  70
1×10 142×0.3 4.60  9.00  1.95  98
1×16 228×0.3 5.60  10.20  1.24  132
1×25 361×0.3 6.95  12.00  0.795 176
1×35 494×0.3 8.30  13.80  0.565 218

Nominal voltage DC: 18KV  AC: 0.6/1.0KV
Voltage test on completed cable AC: 18KV  DC: 15KV,5MIN
Ambient temperature -40°C~+90°C
Max. Temperature at conductor +120°C
Service life >25 year  (-40°C~+90°C)
Refer to short cirauit allows the temperature 200°C, 5(s)
Bending radius ≥4xø(D<8mm), ≥6xø(D≥8mm)
Resistance against acid and alkaline solution EN60811-2-1
Cold bending test EN60811-1-4
Weathering/UV-resistance HD605/A1
0-zone resistance at complete cable EN50396
Test under fire conditions EN60332-1-2
