Staircase Switch TRT8

Basic Information

Current rating 1x16A(AC1)

Voltage range AC/DC 24-240V 50Hz

Applications

Blue tooth time control relay can be used for industrial equipment, lighting control, heating element control, motor and fan control, and regularly turn on and off loads.

Feature


The relay is set through Bluetooth connection of mobile phone app, which
is simple and easy to operate.
8/16 group timing setting.
It has two working modes: automatic and manual.
It has AC / DC 24v-240v ultra wide working voltage.
 Relay status is indicated by LED.
1-MODULE,DIN rail mounting.


Technical Parameters

Model	TRT8-TS1	TRT8-TS2
Function	Bluetooth time control relay
Supply terminals	A1-A2
Voltage range	AC/DC 24-240V 50Hz
Burden	AC 0.09-3VA/DC 0.05-1.7W
Supply voltage tolerance	-15%;+10%
Supply indication	green LED
Number of timers	8-ON/8-OFF	2×8-ON/2×8-OFF
Time setting	APP(Bluetooth connectivity)
Time deviation	±2s/day
Output	1xSPDT	2xSPDT
Current rating	1x16A(AC1)
Min.breaking capacity DC	500mW
Output indication	red LED
Mechanical life	1×10000000
Electrical life(AC1)	1×100000
Operating temperature	-20℃~+55℃
Storage temperature	-35℃~+75℃
