TSP8 Surge Protector

Specification

Type		2P, 4P, 1P+NPE, 3P+NPE
Nominal Discharge Current (8/20us)(In)		5kA		1 0kA		20kA
Max. Discharge Current (8/20us)(lmax)		1 OkA		20kA		40kA
Max. Continuous Operating Voltage (a.c.)(Uc)		1 50V	280V	320V	385V	440V	255V(NPE)
Voltage Protection Level (Up)	TSP8-10	0.7kV	0.8kV	1.0kV	1 .2kV	1.6kV	1.5kV
	TSP8-20	0.8kV	1.0kV	1.2kV	1.45kV	1.6kV	1.5kV
	TSP8-40	1.0kV	1.3kV	1.4kV	1.8kV	2.2kV	1.5kV
SPD According to EN61643-11		Type 2/Class IT2
Response Time (tA)		25ns/ NPE: 100ns
Operating Temperature Range (Tu)		-40°C~+80°C
Operating State / Fault Indication		2P, 4P: Green: normal Red: invalid
Degree of Protection		P20
